Dimensions in m/m

AUTO

rocker switch

FE-A2701

Single Pole Double Throw Switch

3 Position Off-On-On

3 Blade terminals

Copper Contacts

Rating : 15Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Lights symbol imprint

FE-A2702

FE-A2703

Single Pole Double Throw Switch

3 Position Off-On-On

3 Blade terminals

Copper Contacts

Rating : 15Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Fuel Meter symbol imprint

Single Pole Double Throw Switch

3 Position Off-On-On

3 Blade terminals

Copper Contacts

Rating : 15Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Washer symbol imprint

FE-A2704

FE-A2705

Single Pole Double Throw Switch

3 Position Off-On-On

3 Terminals

Copper Contacts

Rating : 25Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Lights symbol imprint

Single Pole Double Throw Switch

3 Position Off-On-On

3 Blade terminals

Copper Contacts

Rating : 25Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Heater Fan symbol imprint

FE-A2706

Single Pole Single Throw Switch

2 Position Off-On

2 Terminals

Copper Contacts

Rating : 25Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Lights symbol imprint

FE-A2707

Single Pole Single Throw Switch

2 Position Off-On

2 Terminals

Copper Contacts

Rating : 25Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With symbol imprint

FE-A2708

Single Pole Double Throw Switch

3 Position Off-On-On

3 Terminals

Copper Contacts

Rating : 25Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Heater Fan symbol imprint

FE-A2709

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Copper Contacts

Rating : 15Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Fuel Meter symbol imprint

FE-A2710

Single Pole Double Throw Switch

3 Position Off-On-On

3 Blade terminals

Copper Contacts

Rating : 15Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Heater Fan symbol imprint

FE-A2711

FE-A2712

FE-A2713

FE-A2714

Single Pole Single Throw Switch

2 Position Off-(On)

2 Terminals

Copper Contacts

Rating : 25Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Washer symbol imprint

3 Position On-On-On

5 Terminals

Copper Contacts

Rating : 25Amps @ 12Volts DC

Mounting : L 38mm / W 28mm

With Wiper symbol imprint

Single Pole Single Throw Switch

2 Position Off-On

3 Blade Terminals

Rating : 10Amps @ 12Volts DC

Rocker Switch with Panel Combination

With Bulb

4 Colors : Red / Amber / Green / Blue

Lighted Switch Kit

2 Position Off-On

Rating : 20Amps @ 12Volts DC

With Bulb

FE-A2715

Rocker Switch Kit

3 Position On-Off-On

Rating : 16Amps @ 125Volts AC / 10Amps @ 250Volts AC

FE-A2716

FE-A2717

FE-A2719

FE-E2701

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Copper Contacts

Single Pole Single Throw Switch

2 Position Off-On

3 Screw terminals

Rating : 16Amps @ 12Volts DC

2 Colors : Red / Amber

Single Pole Single Throw Switch

3 Position Off-On

3 Blade terminals

Copper Contacts

Rating : 16Amps @ 12Volts DC

FE-E2701C

FE-E2702

Single Pole Single Throw Switch

2 Position Off-On

2 Pins

Single Pole Single Throw Switch

Same as FE-E2701 but with Silicone Cover

2 Position Off-On

2 Pins

FE-E2702C

FE-E2705

FE-E2709

FE-A272992A2G0

FE-A272992A2M1

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Rating : 12Volts DC

4 Colors : Red / Amber / Green / Black

FE-E2702M 2 Position Off-(On)

Single Pole Single Throw Switch

Same as FE-E2702 but with Silicone Cover

2 Position Off-On

2 Pins

Single Pole Single Throw Switch

2 Position Off-On

2 Pins

3P Single Pole Single Throw Switch

2 Position Off-On(With LED) / Off-(On)

Rating : 12Volts DC

2 Pins


Single Pole Single Throw Switch

2 Position On-Off

Contact resistance : 20mΩ max. (initial)

Insulation resistance : 100mΩ min. (at 500V DC)

Dielectric strength : 1500V AC 50/60 Hz for 1 min.

Service life : Mechanically-100000 operations min.

                  Electrically-30000 operations min.

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC


Single Pole Single Throw Switch

2 Position (On)-Off

Contact resistance : 20mΩ max. (initial)

Insulation resistance : 100mΩ min. (at 500V DC)

Dielectric strength : 1500V AC 50/60 Hz for 1 min.

Service life : Mechanically-100000 operations min.                       Electrically-30000 operations min.

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC


FE-A272993A2G101LA/B/R/G


Single Pole Single Throw Switch

2 Position On-Off

Contact resistance : 20mΩ max. (initial)

Insulation resistance : 100mΩ min. (at 500V DC)

Dielectric strength : 1500V AC 50/60 Hz for 1 min.

Service life : Mechanically-100000 operations min.

                  Electrically-30000 operations min.

Rating : 20Amps @ 12Volts DC

With 4 colors LED lamp : Red , Amber , Blue , Green

FE-A272993A2M1G101LB/R


Single Pole Single Throw Switch

2 Position (On)-Off

Contact resistance : 20mΩ max. (initial)

Insulation resistance : 100mΩ min. (at 500V DC)

Dielectric strength : 1500V AC 50/60 Hz for 1 min.

Service life : Mechanically-100000 operations min.                       Electrically-30000 operations min.

Rating : 20Amps @ 12Volts DC

With 4 colors LED lamp : Red , Blue

FE-A272993A3G0


Single Pole Double Throw Switch

3 Position On-Off-On

Contact resistance : 20mΩ max. (initial)

Insulation resistance : 100mΩ min. (at 500V DC)

Dielectric strength : 1500V AC 50/60 Hz for 1 min.

Service life : Mechanically-100000 operations min.                       Electrically-30000 operations min.

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC

FE-A272994A3G11-2LRA


Single Pole Double Throw Switch

3 Position On-Off-On

Contact resistance : 20mΩ max. (initial)

Insulation resistance : 100mΩ min. (at 500V DC)

Dielectric strength : 1500V AC 50/60 Hz for 1 min.

Service life : Mechanically-100000 operations min.                       Electrically-30000 operations min.

Rating : 20Amps @ 12Volts DC

With 2 LED lamp : Red , Amber

FE-A272996A3G0

FE-A272996A3G11-2LRA


Double Pole Double Throw Switch

3 Position On-Off-On

Contact resistance : 20mΩ max. (initial)

Insulation resistance : 100mΩ min. (at 500V DC)

Dielectric strength : 1500V AC 50/60 Hz for 1 min.

Service life : Mechanically-100000 operations min.                       Electrically-30000 operations min.

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC


Double Pole Double Throw Switch

3 Position On-Off-On

Contact resistance : 20mΩ max. (initial)

Insulation resistance : 100mΩ min. (at 500V DC)

Dielectric strength : 1500V AC 50/60 Hz for 1 min.

Service life : Mechanically-100000 operations min.                       Electrically-30000 operations min.

Rating : 20Amps @ 12Volts DC

With 2 LED lamp : Red , Amber



Dimensions in m/m

AUTO

Hazard switch

FE-A2721


Hazard Switch

2 Position On-On
6 Blade Terminals: 4.8mmx0.5mm
Bronze and Copper Contacts
Rating:12-24 Volts
Applications: Hazard Switch
for Triumph TR250 TR5 TR6 TR7 TR8 GT6 STAG



Dimensions in m/m

AUTO

ELECTRIC WINdow switch

FE-A2722


Electric Window Switch

3 Position (On)-On-(On)
6 Pin Terminals : 3mm
Copper Contacts
Rating:12-24 Volts
Applications: Electric Window Lift Switch
for Triumph Stag MK1 & MK2
