Dimensions in m/m

AUTO

ignition starter switch

FE-A1101

ignition starter switch/FE-A1101/key set/universal type/Delco U-1403

4 Position ACC-Off-On-Start , 2 Keys

4 Stud terminals

Copper Contacts

Rating : 30Amps @ 12Volts DC

Mounting Stem : 7/16” Long / 3/4” Diameter

                        1 1/8” Mounting Nut

Universal Type

Key is only removable in the Off position

Applications : Delco U-1403


FE-A1104


Single Throw Ignition Starter Switch

2 Position Off-On , 2 Keys

2 Terminals

Bronze Contacts

Rating : 15Amps @ 6Volts DC / 10Amps @ 12Volts DC

Mounting Stem : 3/4” Long / 3/4” Diameter

                        1/8” Mounting Nut

Universal Type

Key is only removable in the Off position

Application : Delco U-1400

FE-A1105


Double Throw Ignition Starter Switch

3 Position On-Off-On , 2 Keys

3 Terminals

Bronze Contacts

Rating : 15Amps @ 6Volts DC / 10Amps @ 12Volts DC

Mounting Stem : 3/4” Long / 3/4” Diameter

                        1 1/8” Mounting Nut

Universal Type

Key is only removable in the Off position

Applications : Delco U-1402

FE-A1106

FE-A1109

ignition starter switch/FE-A1106/key set/national cabinet lock

Switch Lock from national cabinet lock

2 Position , 2 Keys

2 Blade terminals

Copper Contacts


3 Position Off-On-Start , 2 Keys

5 Blade terminals

Copper Contacts

Key is only removable in the Off position

Replaces Lucas Part No.31973K4183 , 31973K4287

Applications : Land Rover


FE-A1110

FE-A1111


4 Position ACC-Off-On-Start , 2 Keys

4 Screw terminals

Bronze Contacts

Key is only removable in the Off position

Applications : Toyota-RS RK-FJ-RA

              Part No.221011-5200 ISC-4

3 Position Off-On-Start , 2 Keys

3 Screw terminals

Copper Contacts

Universal Type

Key is only removable in the Off position

Applications : Mitsubishi A-10 / Mini Car 300 / Colt 600


FE-A1112


4 Position ACC-Off-On-Start , 2 Keys

4 Screw terminals

Copper Contacts

Key is only removable in the Off position

Applications : Toyota ISC-7 Part No. 221035-5200

FE-A1114


3 Position Off-On-Start , 2 Keys

3 Screw terminals

Copper Contacts

Universal Type

Key is only removable in the Off position

Applications : Toyota ISC-5R Part No. 221126-5201


FE-A1115


3 Position Off-On-Start , 2 Keys

3 Screw terminals

Copper Contacts

Key is only removable in the Off position

Applications : Suzuki ST-20 , ST-90 / Jeep / Pick up / Mini Bus


FE-A1116

FE-A1118


4 Position ACC-Off-On-Start , 2 Keys

4 Blade terminals(Plug in type)

Copper Contacts

Key is only removable in the Off position

Applications : Toyota ISC-9 Part No. 221067-5200


4 Position ACC-Off-On-Start , 2 Keys

5 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Isuzu KB-20 / Mitsubishi Colt L-300

ignition starter switch/FE-A1119/key set/universal type/Dutsun 520,620/Nissan

4 Position ACC-Off-On-Start , 2 Keys

4 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Dutsun Sunny 120Y , B310


FE-A1119

4 Position ACC-Off-On-Start , 2 Keys

5 Blade terminals

Nickel plated Iron Contacts

Universal Type

Key is only removable in the Off position

Applications : Dutsun 520 , 620 / Nissan

FE-A1120


3 Position Off-On-Start , 2 Keys

3 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Dutsun Sunny 120Y , B310


FE-A1121

ignition starter switch/FE-A1123/key set/Isuzu Bus&Truck SS-54-3

4 Position ACC-Off-On-Start , 2 Keys

6 Screw terminals

Bronze Contacts

Rating : 12Volts

Key is only removable in the Off position

Applications : Isuzu Bus&Truck SS-54-3


FE-A1123

ignition starter switch/FE-A1124/key set/Toyota ISC-8R 222124-5200/Mitsubishi/Hino Truck&Bus

4 Position ACC-Off-On-Start , 2 Keys

6 Screw terminals

Copper Contacts

Key is only removable in the Off position

Applications : Toyota ISC-8R Part No. 222124-5200 /

 Mitsubishi / Hino Truck&Bus

FE-A1124

4 Position ACC-Off-On-Start , 2 Keys

6 Screw terminals

Copper Contacts

Rating : 24Volts

Universal Type

Key is only removable in the Off position

Applications : HKT SI-05 / Mitsubishi

ignition starter swtch/FE-A1125/ket set/universal type/HKT SI-05/Mitsubishi

FE-A1125

ignition starter swich/FE-A1126/key set/Toyota ISC-24

4 Position ACC-Off-On-Start , 2 Keys

6 Screw terminals

Copper Contacts

FE-A1124 with wire & connector

Key is only removable in the Off position

Applications : Toyota ISC-24


FE-A1126

ignition starter switch/FE-A1127/ket set/Delco/IHC/Jeep

Ignition Starter Switch with lock cylinder and Keys

4 Position ACC-Off-On-Start , 2 Keys

11 Blade terminals

Iron Contacts

Rating : 12Volts

Key is only removable in the Off position

Applications : Delco / IHC / International / Jeep


FE-A1127

FE-A1128

ignition starter switch/FE-A1128/key set/Volkswagen

3 Position Off-On-Start , 2 Keys

3 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Volkswagen

Ignition starter switch/drawing of FE-A1128

FE-A1129

ignition starter switch/drawing of FE-A1129

3 Position Off-On-Start , 2 Keys

3 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Volkswagen


3 Position Off-On-Start , 2 Keys

7 Blade terminals

Copper Contacts

Rating : 12-24Volts

Key is only removable in the Off position

Replaces Lucas Part NO.35288

Applications : Land Rover


FE-A1130

ignition starter switch/FE-A1131/key set/universal type/Renault

3 Position Off-On-Start , 2 Keys

5 terminals

Copper Contacts

Universal Type

Key is only removable in the Off position

Applications : Renault

FE-A1131


Ignition Starter Switch with coded tumbler lock

3 Position , 2 Keys

4 Screw terminals

Bronze Contacts

Rating : 15Amps @ 12Volts DC

Mounting Stem : 13/16”-24 Thread

O-ring sealed at stem

Key is only removable in the Off position

ignition starter switch/drawing of FE-A1133

FE-A1133
