Dimensions in m/m

AUTO

headlamp dimmer switch

FE-A1401

headlamp dimmer switch/FE-A1401/SPDT/Jeep 931201
headlamp dimmer switch/drawing of FE-A1401

Single Pole Double Throw Switch

2 Position On-On

3 Blade terminals

Bronze Contacts

Applications : Jeep 931201

FE-A1402

headlamp dimmer switch/FE-A1402/SPDT
headlamp dimmer switch/drawing of FE-A1402

Single Pole Double Throw Switch

2 Position On-On

3 Blade terminals

Bronze Contacts

FE-A1403

FE-A1404

FE-A1405

FE-A1406

headlamp dimmer switch/FE-A1403/SPDT/Chrysler/Ford/Studebaker
headlamp dimmer switch/FE-A1404/SPDT/Jeep 931201
headlamp dimmer switch/FE-A1405/SPDT/Ford/Studebaker/Willy
headlamp dimmer switch/FE-A146/waterproof/dustproof

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Mounting Stem : 3/4” and 1 3/4” on centers

      / 1/4”-20 Thread

Rating : 12Amps @ 12Volts DC

Waterproof and dustproof

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Mounting Stem : 3/4” and 1 3/4” on centers / 1/4”-20 Thread

Applications : Ford / Studebaker / Willys

Single Pole Double Throw Switch

Same as FE-A1401

2 Position On-On

3 Blade terminals

Bronze Contacts

Applications : Jeep 931201

Single Pole Double Throw Switch

2 Position On-On

3 Blade terminals

Bronze Contacts

Applications : Chrysler / Ford / Studebaker

FE-A1407

headlamp dimmer switch/FE-A1407/R-type connectors/waterproof/dustproof

Same as FE-A1406 but with Wire Leads

2 Position Off-(On)

2 Terminals

R-type connectors

Mounting Stem : 3/4” and 1 3/4” on centers

      / 1/4”-20 Thread

Rating : 12Amps @ 12Volts DC

Waterproof and dustproof

FE-A1408

headlamp dimmer switch/FE-A1408/SPDT/Merit 322200
headlamp dimmer switch/drawing of FE-A1408

Single Pole Double Throw Switch

2 Position On-On

3 Blade terminals

Bronze Contacts

Rating : 8Amps @ 12Volts DC / 4Amps @ 24Volts DC

Applications : Merit 322200

FE-A1408-1

headlamp dimmer switch/FE-A1408-1/SPDT/iro cap/Merit 322200
headlamp dimmer switch/drawing of FE-A1408-1

Single Pole Double Throw Switch

Same as FE-A1408 but with Iron Cap

2 Position On-On

3 Blade terminals

Bronze Contacts

Rating : 8Amps @ 12Volts DC / 4Amps @ 24Volts DC

Applications : Merit No. 322200

FE-A1409

FE-A1409-1

headlamp dimmer switch/FE-A1409/SPDT/Merit 322100
headlamp dimmer switch/drawing o FE-A1409

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Bronze Contacts

Rating : 8Amps @ 12Volts DC / 4Amps @ 24Volts DC

Applications : Merit No. 322100

headlmp dimmer switch/drawing of FE-A1409-1/SPDT/iron cap/Merit 322100

Single Pole Double Throw Switch

Same as FE-A1409 but with Iron Cap

2 Position On-On

3 Screw terminals

Bronze Contacts

Rating : 8Amps @ 12Volts DC / 4Amps @ 24Volts DC

Applications : Merit No. 322100

headlamp dimmer swich/drawing of FE-A1409-1

FE-A1410

headlamp dimmer switch/FE-A1410/SPDT/universal and haevy duty type

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Universal and Heavy Duty type

headlamp dimmer switch/drawing of FE-A1410
headlamp dimmer switch/FE-A1411/SPDT/Chrysler/Ford

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Mounting Stem : 1 3/4” on centers

                        1/4”-20 Thread / 7/8” Diameter

Applications : Chrysler / Ford

headlamp dimmer switch/drawing of FE-A1411
headlamp dimer switch/FE-A1412/SPDT/weather resistant seal in case

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Mounting Stem : 3/4” and 1 3/4” on centers

1/4”-20 Thread / 7/8” Diameter

Weather resistant seal in case

headlamp dimmer switch/drawing of FE-A1412
hedlamp dimmer switch/FE-A1414/SPDT

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Mounting Stem : 3/4” and 1 3/4” on centers

                        1/4”-20 Thread / 1 1/16” Diameter

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

headlamp dimmer switch/drawing FE-A1414

FE-A1411

FE-A1412

FE-A1413

FE-A1414

other

switch

AUTO

Dimensions in m/m



FE-A1601

2 Speed Heavy Duty Axle Switch

2 Position On-On

3 Snap-in terminals

Copper Contacts

Rating : 30Amps @ 12Volts DC

Die-Casting Body

Protected with rubber cover

Applications : Ford / IHC / Chrysler

2 speed heavy duty axle switch/die-casting body/rubber cover/Ford/IHC/Chrysler
2 speed heavy duty axle switch/drawing of FE-A1601

FE-A1602

Terminal Block Switch

2 Position On-On

4 Screw terminals

Copper Contacts

Mounting Stem : 8-32 Studs, 3/4” Long / 8-32 Studs, 7/32” Long

Applications : Ford / IHC / Chrysler / GMC

terminals block switch/Ford/IHC/Chrysler/GMC
terminal block switch/dawing of FE-A1602

FE-A1603

FE-A1605

FE-A1606

FE-A1607

FE-A1608

FE-A1609

FE-A1610

3 Terminals

R-type Connectors

Cable Accessory

Cord Only

Applications : Ford FAB 14668B

Fuel Pressure Regulator

With fittings and clamps

Chrome plated Zinc cast

Applications : Volkswagen 10-5622

Dashboard Lock

With 2 Keys

Key is only removable in the Off position

Fan Switch for Auto

Rating : 12Volts DC / 0.1~3.5Ω

R-type connectors/FE-A1603/Ford FAB 14668B
fuel pressure regulator/FE-A1605/Volkswagen 10-5622
dashboard lock/FE-A1606
fan switch/FE-A1607/0.1~3.5Ω
R-type connectors/drawing of FE-A1603
fan switch/drawing of FE-A1607

Remote Charging Terminal

Jumper Post are Black in color

Used as the negative connection for charging the battery

Terminals have insulated covers

remote charging terminal/FE-A1609/black jumper post/negative connection/insulated covers
through panel connector/FE-A1610/for firewall or bulkhead

Through Panel Connector

For firewall or bulkhead

Positive(Red) and negative(Black)

through panel battery connector


Remote Charging Terminal

Jumper Post are Red in color

Used as the positive connection for charging the battery

Terminals have insulated covers
