Dimensions in m/m

AUTO

toggle

switch

FE-A1727

FE-A1728

FE-A1729

FE-A1730

FE-A1731

FE-A1732

FE-A1733

FE-A1734

FE-A1736

FE-A1737

Single Pole Single Throw Switch

2 Position Off-On

3 Blade terminals

Copper Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 1/4” Long

4 Colors : Red / Amber / Green / Blue

With Bulb

Single Pole Double Throw Switch

2 Position On-On

3 Blade terminals

Copper Contacts

Rating : 10Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 1/4” Long

FE-A1728A 3 Position On-Off-On

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Copper Contacts

Rating : 10Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 1/4” Long

FE-A1727A 2 Position Off-(On)

Long Type Horn Switch

Single Pole Single Throw Switch

2 Position Off-(On)

2 Blade terminals

Copper Contacts

Mounting Stem : 15/32” Diameter / 15/32” Long

Short Type Horn Switch

Single Pole Single Throw Switch

2 Position Off-(On)

2 Blade terminals

Copper Contacts

Mounting Stem : 15/32” Diameter / 15/32” Long

Application : Merit 32100

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Copper Contacts

Rating : 15Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 1/4” Long

Single Pole Single Throw Switch

2 Position Off-On

3 Blade terminals

Rating : 10Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 1/4” Long

4 Colors : Red / Yellow / Green / Blue

With LED

Single Pole Single Throw Switch

2 Position Off-On

3 Blade terminals

Copper Contacts

Rating : 10Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 1/4” Long

5 Colors : Red / Yellow / Green / Blue / Black

With Bulb

FE-A1730A-BK 3 Pin SPDT / 3 Position On-Off-On

FE-A1730B-BK 3 Pin SPDT / 2 Position On-On

FE-A1730C-BK 2 Pin SPST / 2 Position Off-On

Single Pole Double Throw Switch

3 Position On-Off-On

3 Screw terminals

Bronze Contacts

Mounting Stem : 15/32” Diameter / 15/32” Long

Single Pole Double Throw Switch

3 Position On-Off-On

3 Screw terminals

Bronze Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1738

Single Pole Double Throw Switch

3 Position On-Off-On

3 Screw terminals

Bronze Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

Application : Merit 32100

FE-A1739

FE-A1740

FE-A1741

FE-A1742

Head Light Switch

3 Position Off-On(I)-On(II)

3 Pin terminals

Copper Contacts

Application : Austin Taxi(Fairway)

                  '86-'87 JIV01-99029

3 Position On-Off-On

5 Blade terminals

Copper Contacts

Rating : 12-24Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

Replaces Lucas Part No. 31788

One Switch

2 Position Off-On

3 Blade terminals

Switch in Plastic Panel

2 Colors : Red / Green

With Bulb

One Switch

2 Position Off-On

2 Blade terminals

Switch in Steel Panel

FE-A1744

FE-A1745

FE-A1746

FE-A1747

FE-A1748

Double Pole Single Throw Switch

3 Position Off-On-On

4 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

With Boot Nut and Special Moisture-Proof

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

With Boot Nut and Special Moisture-Proof

Single Pole Single Throw Switch

Same as FE-A1744 but with Waterproof Rubber Cover

2 Position Off-On

2 Blade terminals

Silver Plated Copper Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

With Boot Nut

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Silver Plated Copper Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1749

FE-A1750

FE-A1751

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Rating : 3Amps @ 125Volts AC

Mounting Stem : 15/32” Diameter / 15/32” Long

Single Pole Single Throw Switch

2 Position Off-On

2 Screw terminals

Iron Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1750A 2 Position Off-(On)

Double Pole Single Throw Switch

3 Position Off-On-(On)

4 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

With Boot Nut and Special Moisture-Proof

Single Pole Single Throw Switch

2 Position Off-On

2 Screw terminals

Rating : 2Amps @ 250Volts AC

Mounting Stem : 15/32” Diameter / 15/32” Long

Double Pole Double Throw Switch

3 Position On-Off-On

6 Screw terminals

Rating : 10Amps @ 125Volts AC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1752

FE-A1753

Double Pole Single Throw Switch

2 Position Off-On

4 Blade terminals

Rating : 3Amps @ 125Volts AC

Mounting Stem : 15/32” Diameter / 15/32” Long
