Dimensions in m/m
AUTO
stop light
switch
FE-A1301
2 Position Off-(On)
2 Screw terminals
Bronze Contacts
Rating : 10Amps @ 12Volts DC
Applications : Merit No. 431300
FE-A1302
Throttle Pull Switch
2 Position Off-(On)
2 Terminals
Copper Contacts
Rating : 10Amps @ 12Volts DC
FE-A1303
FE-A1304
FE-A1305
FE-A1306
FE-A1307
FE-A1308
2 Position On-(Off)
2 Blade terminals
Copper Contacts
Applications : Ford / Chrysler / IHC
2 Position On-(Off)
2 Blade terminals
Copper Contacts
Applications : Fiat
2 Position On-(Off)
2 Blade terminals
Copper Contacts
Applications : Fiat
Door / Momentary Switch
2 Position On-(Off)
2 Terminals with Male Housing
Applications : Toyota
Door / Momentary Switch
2 Position On-(Off)
2 Terminals
2 Male Bullet Connectors
Applications : Datsun / Daihatsu / Subaru
Door / Momentary Switch
2 Position On-(Off)
2 Terminals
2 Male Bullet Connectors
Applications : Toyota / Mitsubishi
FE-A1309
Door / Momentary Switch
2 Position On-(Off)
2 Terminals
2 Male Bullet Connectors
Applications : Toyota
Dimensions in m/m
AUTO
cable
switch
FE-A2101
Cable Switch
7 Blade terminals
Bronze Contacts
Replaces Lucas Pakan
FE-A2107
Cable Switch
3 Wires(Red / Black / Gray)
Wires are installs into the bottom of the
steering column lock assembly
Applications : Volkswagen
FE-A2108
Cable Switch
5 Blade terminals
Bronze Contacts
Replaces Lucas Part No. 35289
Applications : Land Rover PRC2735
Dimensions in m/m
AUTO
circuit
breaker
FE-A2501
Automatic reset circuit breaker
2 Stud terminals
Rating : 20 / 30 / 40 / 50Amps @ 12Volts
Zinc plated metal cover without bracket
FE-A2502
FE-A2503
Automatic reset circuit breaker
2 Stud terminals
Rating : 10 / 15 / 20 / 25 / 30 / 40 / 50Amps @ 12Volts
Zinc plated metal cover with horizontal bracket
Automatic reset circuit breaker
2 Blade terminals
Rating : 20 / 30 / 40 Amps @ 12Volts
Zinc plated metal cover
39.1
Dimensions in m/m
AUTO
car cigarette
lighter
FE-A4601
Car Cigarette Lighter
Without button
FE-A4602
Car Cigarette Lighter
With button(FE-E2709)
Rating : 12Volts DC
FE-A4603-BK/A4603-GRAY
Dimensions in m/m
AUTO
turn signal
switch
Car Cigarette Lighter
With button(FE-E2709)
Same as FE-A4602 but extension cable set
Rating : 12Volts DC
Cable set 2 Colors : Black / Gray
FE-A4701
Turn Signal Switch for truck
For use on vehicles having combination stop and
turn signal lamps and requiring brake light circuit
3 Positions
Chrome plated Zinc die cast
Die cast handle
Long lasting contacts extend switch life
Heavy Duty wiring 7-wire harness
Universal Type
FE-A4702
Turn Signal Switch for truck
For use on vehicles having combination stop and
turn signal lamps and requiring brake light circuit
3 Positions
Chrome plated Zinc die cast
Die cast handle
Long lasting contacts extend switch life
Heavy Duty wiring 7-wire harness
Universal Type
FE-A4703
Turn Signal Switch for truck
For use on vehicles having combination stop and turn signal lamps and requiring brake light circuit
3 Positions
Zinc die cast
Die cast handle
Long lasting contacts extend switch life
Heavy Duty wiring 7-wire harness
Universal Type
FE-A4703-1B
FE-A4703-1C
FE-A4703-1D
FE-A4703-1E
FE-A4705
Turn Signal Switch Wiring
8 Wires
Wiring harness
Turn signal-canceling camera
Built-in horn switch
Applications : Ford
FE-A4705-1
Turn Signal Repair
2 Wires
Applications : Ford
Turn Signal Switch
6 wires with terminals
