Dimensions in m/m

AUTO

toggle

switch

FE-A1701

FE-A1702

Single Pole Single Throw Switch

2 Position On-Off

2 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1701A 2 Position Off-(On)


Single Pole Single Throw Switch

2 Position On-Off

2 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1702A 2 Position Off-(On)


FE-A1703

FE-A1704

FE-A1705

FE-A1706

Single Pole Double Throw Switch

3 Position On-Off-On

3 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1703A 2 Position On- On

FE-A1703B 3 Position (On)-Off-On

FE-A1703C 3 Position (On)-Off-(On)


Double Pole Single Throw Switch

2 Position Off-On

4 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1704A 2 Position Off-(On)


Double Pole Single Throw Switch

2 Position Off-On

4 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1705A 2 Position Off-(On)


Double Pole Double Throw Switch

3 Position On-Off-On

6 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1706A 2 Position On-On

FE-A1706B 3 Position (On)-Off-On

FE-A1706C 3 Position (On)-Off-(On)


FE-A1707

Double Pole Double Throw Switch

3 Position On-Off-On

6 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1707A 2 Position On-On

FE-A1707B 3 Position (On)-Off-On

FE-A1707C 3 Position (On)-Off-(On)


FE-A1708

FE-A1709

Single Pole Single Throw Switch

2 Position Off-On

2 Screw terminals

Nickel plated Bronze Contacts

Rating : 10Amps @ 125Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1708A 2 Position Off-(On)


FE-A1710

Single Pole Single Throw Switch

2 Position Off-On

2 Screw terminals

Bronze Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1709A 2 Position Off-(On)


Single Pole Single Throw Switch

2 Position Off-On

2 Screw terminals

Bronze Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1710A 2 Position Off-(On)


FE-A1711

Single Pole Double Throw Switch

3 Position On-Off-On

3 Screw terminals

Nickel plated Bronze Contacts

Rating : 10Amps @ 125Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1711A 2 Position On-On

FE-A1711B 3 Position (On)-Off-On

FE-A1711C 3 Position (On)-Off-(On)


FE-A1712

FE-A1713

FE-A1714

FE-A1715

Single Pole Double Throw Switch

3 Position On-Off-On

3 Screw terminals

Bronze Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1712A 2 Position On-On

FE-A1712B 3 Position (On)-Off-On

FE-A1712C 3 Position (On)-Off-(On)


Double Pole Single Throw Switch

2 Position Off-On

4 Screw terminals

Bronze Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1713A 2 Position Off-(On)


Double Pole Single Throw Switch

2 Position Off-On

4 Screw terminals

Bronze Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1714A 2 Position Off-(On)


Double Pole Double Throw Switch

3 Position On-Off-On

6 Screw terminals

Bronze Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1715A 2 Position On-On

FE-A1715B 3 Position (On)-Off-On

FE-A1715C 3 Position (On)-Off-(On)


FE-A1716


Double Pole Double Throw Switch

3 Position On-Off-On

6 Screw terminals

Bronze Contacts

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1716A 2 Position On-On

FE-A1716B 3 Position (On)-Off-On

FE-A1716C 3 Position (On)-Off-(On)

FE-A1717

FE-A1718

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1717A 2 Position Off-(On)


Single Pole Double Throw Switch

3 Position On-Off-On

3 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1718A 2 Position On-On

FE-A1718B 3 Position (On)-Off-On

FE-A1718C 3 Position (On)-Off-(On)


FE-A1719

Single Pole Single Throw Switch

2 Position Off-On

2 Screw terminals

Copper Contacts

Rating : 50Amps @ 6-24Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1719A 2 Position Off-(On)


FE-A1720


Single Pole Double Throw Switch

3 Position On-Off-On

3 Screw terminals

Copper Contacts

Rating : 50Amps @ 6-24Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1720A 2 Position On-On

FE-A1720B 3 Position (On)-Off-On

FE-A1720C 3 Position (On)-Off-(On)

FE-A1721

FE-A1722

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1721A 2 Position Off-(On)


Single Pole Double Throw Switch

3 Position On-Off-On

3 Blade terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1722A 2 Position On-On

FE-A1722B 3 Position (On)-Off-On

FE-A1722C 3 Position (On)-Off-(On)


FE-A1723

FE-A1724

Single Pole Single Throw Switch

2 Position Off-On

2 Screw terminals

Copper Contacts

Rating : 50Amps @ 6-24Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1723A 2 Position Off-(On)


Single Pole Double Throw Switch

3 Position On-Off-On

3 Screw terminals

Copper Contacts

Rating : 50Amps @ 6-24Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1724A 2 Position On-On

FE-A1724B 3 Position (On)-Off-On

FE-A1724C 3 Position (On)-Off-(On)


FE-A1725

Single Pole Double Throw Switch

3 Position On-Off-On

3 Screw terminals

Copper Contacts

Rating : 50Amps @ 6-24Volts DC

Mounting Stem : 15/32” Diameter / 15/32” Long

FE-A1725A 2 Position On-On

FE-A1725B 3 Position (On)-Off-On

FE-A1725C 3 Position (On)-Off-(On)
