toggle switch(1779~1799)

Dimensions in m/m

AUTO

toggle

switch

FE-A1779

FE-A1780

FE-A1781

FE-A1782

FE-A1783

FE-A1784

FE-A1785


Single Pole Double Throw Switch

FE-A1778 but with Waterproof Rubber Cover

3 Position On-Off-On

3 Blade terminals

Nickel plated Bronze Contacts

Rating : 20Amps @ 12Volts DC

Double Pole Single Throw Switch

2 Position Off-On

4 Blade terminals

Copper Contacts

Replaces Lucas Part No. 31780

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Nickel plated Bronze Contacts

Rating : 20Amps @ 12Volts DC

FE-A1781A 2 Position Off-(On)

Single Pole Single Throw Switch

2 Position Off-On

2 Pin

Rating : 3Amps @ 250Volts AC

Double Pole Double Throw Switch

3 Position On-Off-On

6 Blade terminals

Nickel plated Bronze Contacts

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC

FE-A1783A 2 Position On-On

FE-A1783B 3 Position (On)-Off-On

FE-A1783C 3 Position (On)-Off-(On)

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Nickel plated Bronze Contacts

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC

Single Pole Double Throw Switch

3 Position On-Off-On

3 Blade terminals

Nickel plated Bronze Contacts

Rating : 15Amps @ 24Volts DC

FE-A1785B 3 Position (On)-Off-On

FE-A1785C 3 Position (On)-Off-(On)

FE-A1786

Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Copper Contacts

FE-A1787

FE-A1788


Double Pole Single Throw Switch

2 Position Off-On

4 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC

FE-A1787A 2 Position Off-(On)

Double Pole Double Throw Switch

3 Position On-Off-On

6 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC

FE-A1788A 2 Position On-On

FE-A1788B 3 Position (On)-Off-On

FE-A1788C 3 Position (On)-Off-(On)


FE-A1789

FE-A1790

FE-A1791

FE-A1792

​FE-A1793


Double Pole Single Throw Switch

2 Position Off-On

4 Blade terminals

Nickel plated Bronze Contacts

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC

FE-A1789A 2 Position Off-(On)

Single Pole Single Throw Switch

2 Position Off-On

2 Screw terminals

Copper Contacts

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC

Single Pole Double Throw Switch

3 Position On-Off-On

3 Screw terminals

Copper Contacts

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC

Double Pole Single Throw Switch

2 Position Off-On

4 Screw terminals

Copper Contacts

Rating : 20Amps @ 12Volts DC /15Amps @ 24Volts DC

Double Pole Double Throw Switch

3 Position On-Off-On

6 Screw terminals

Copper Contacts

Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC

​FE-A1794

Single Pole Double Throw Switch

2 Position On-On

3 Pin

Rating : 6Amps @ 125Volts AC / 3Amps @ 250Volts AC

​FE-A1796


Double Pole Single Throw Switch

3 Position (On)-Off-On

4 Screw terminals

Bronze Contacts

​FE-A1797


Single Pole Single Throw Switch

2 Position Off-On

2 Blade terminals

Silver plated Bronze Contacts

Rating : 6Amps @ 125Volts AC / 3Amps @ 250Volts AC

​FE-A1797C

​FE-A1797C-1

​FE-A1798

​FE-A1799


Single Pole Single Throw Switch

FE-A1797 but with Waterproof Rubber Cover

2 Position Off-On

2 Blade terminals

Silver plated Bronze Contacts

Rating : 6Amps @ 125Volts AC / 3Amps @ 250Volts AC

Single Pole Single Throw Switch

2 Position Off-(On)

2 Blade terminals

Copper Contacts

Double Pole Double Throw Switch

2 Position Off-On

6 Blade terminals

Bronze Contacts


Single Pole Single Throw Switch

FE-A1797 but with Waterproof Rubber Cover

2 Position Off-On

2 Blade terminals

Silver plated Bronze Contacts

Rating : 6Amps @ 125Volts AC / 3Amps @ 250Volts AC
