push button switch

Dimensions in m/m

AUTO

Push button switch

FE-A1201

push button switch/FE-A1201/SPST/Chrysler/IHC

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 25Amps @ 6Volts DC / 15Amps @ 12Volts DC

Mounting Stem : 5/8” Diameter

Universal type

Applications : Chrysler / IHC


FE-A1202

push button switch/drawing of FE-A1202

Starter Button Switch

2 Position Off-(On)

1 Terminal

Iron / Bronze Contact

Rating : 15Amps @ 6Volts DC

           10Amps @ 12Volts DC

            6Amps @ 24Volts DC

push button switch/FE-A1202

FE-A1203

Door Jamb Switch

Single Pole Single Throw

2 Position (Off)-On

2 Screw terminals

Copper Contacts

Rating : 5Amps @ 12Volts DC

Mounting Stem : 1 3/8” and 2 1/16” on centers

Universal type / insulated

Applications : Chrysler 882943

push buttn switch/door jamb switch/drawing of FE-A1203
push button switch/door jamb switch/FE-A1203/SPST/universal type/Chrysler 882943

FE-A1204

Horn Button Switch

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 5Amps @ 12Volts DC

Chrome surface

push button switch/horn button switch/drawing of FE-A1204
push button switch/horn button switch/drawing of FE-A1204
push button switch/horn button switch/FE-A1204

FE-A1205

push button switch/horn button switch/drawing of FE-A1205

Horn Button Switch

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 5Amps @ 12Volts DC

Chrome surface

push button switch/horn button switch/FE-1205

FE-A1206


Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Applications : Merit No. 201000


FE-A1206S


Starter Button Switch

Single Pole Single Throw

Same as FE-A1206 but using heat resistant material

2 Position Off-(On)

2 Screw terminals

Silver Plated Bronze Contacts

Rating : 30Amps @ 12Volts DC

push button switch/FE-A1206S/SPST/heat resistant material

FE-A1207


Starter Button Switch

Single Pole Single Throw

Same as FE-A1206 but with Waterproof Rubber Cover

2 Position Off-(On)

2 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC


FE-A1209

FE-A1210


Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Copper Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 15.87 m/m Long / 5/8” Diameter

Replaces Pollak Part No. 21-360

Applications : Delco 1996097

push button switch/FE-A1210/SPST/Pollak 21-360/Delc 1996097

2 Position Off-(On)

Single Pole Single Throw

2 Blade terminals

Silver Plated Bronze Contacts

Rating : 15Amps @ 12Volts DC

Mounting Stem : 7/8” (22.2mm) Diameter

push button switch/FE-A1209/SPST

FE-A1211

push button switch/FE-A1211/SPST

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 25Amps @ 6Volts DC

            / 15Amps @ 12Volts DC


FE-A1212

push button switch/FE-A1212/SPST

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Silver Plated Bronze Contacts

Rating : 15Amps @ 125Volts AC

            / 10Amps @ 250Volts AC


FE-A1213

push button switch/FE-A1213/SPST/Merit

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Applications : Merit 201000


FE-A1214

heavy duty push button switch/FE-A1214/SPST

Heavy Duty Push Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Copper Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 5/8”-32 Thread

Chrome plated face nut


FE-A1215

push button switch/door jamb switch/FE-A1215/SPST/Delco 1972532/Ford 1965-79/Mercury 1965-79

Door Jamb Switch

Single Pole Single Throw

2 Position (Off)-On

2 Screw terminals

Bronze Contacts

Applications : Delco 1972532 / Ford 1965-79 / Mercury 1965-79

push button switch/door jamb switch/drawing of FE-1215

FE-A1216

push button switch/FE-A1216
push button switch/drawing of FE-A1216

Starter Button Switch

2 Position Off-(On)

1 snap-in terminal

Bronze Contact

Rating : 15Amps @ 6Volts DC

           10Amps @ 12Volts DC

            6Amps @ 24Volts DC

FE-A1219

push button switch/FE-A1219/SPST

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Copper Contacts

Rating : 15Amps @ 120Volts AC

            10Amps @ 240Volts AC


FE-A1219C

push button switch/FE-A1219C/SPST/waterproof/sikicone cover

Starter Button Switch

Single Pole Single Throw

Same as FE-A1219 but with Silicone Cover

2 Position Off-(On)

2 Blade terminals

Copper Contacts

Rating : 15Amps @ 120Volts AC

           10Amps @ 240Volts AC


FE-A1220


Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 15Amps @ 12Volts DC


FE-A1220C

push button switch/FE-A1220C/SPST/waterproof rubber cover

Starter Button Switch

Single Pole Single Throw

Same as FE-A1220 but with Rubber Cover

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 15Amps @ 12Volts DC


FE-A1221

push button swich/FE-A1221

Starter Button Switch

2 Position Off-(On)

2 Wires (150mm)

Rating : 3Amps @ 250Volts AC

6Amps @ 125Volts AC

Button : Brass with Nickel Plated


FE-A1222

Starter Button Switch

Single Pole Single Throw

Same as FE-A1201 but with Rubber Cap

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 25Amps @ 6Volts DC / 15Amps @ 12Volts DC

Mounting Stem : 5/8” Diameter

Universal type

Applications : Chrysler / IHC

push button switch/FE-A1222/SPST/waterproof rubber cover/universal type/Chrysler/IHC

FE-A1223

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Silver Plated Bronze Contacts

Rating : 15Amps @ 125Volts AC / 10Amps @ 250Volts AC

push button switch/FE-A1223/SPST

FE-A1224

Door Contact Switch

Single Pole Single Throw

2 Position (Off)-On

2 Blade terminals

Copper Contacts

Rating : 15Amps @ 12Volts DC

push button switch/door contact switch/FE-A1224/SPST

FE-A1225

Push Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

push button switch/FE-A1225/SPST

FE-A1226

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Copper Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 5/8”(15.87mm) Diameter

With Rubber Cover and Mounting Nut

Replaces Pollak Part No. 21-360

Applications : Delco 1996097

push button switch/FE-A1226/SPST/waterproof rubber cover/Pollak 21-360/Delco 1996097

Push Button Switch

2 Position Off-(On)

2 Screw terminals

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32”(12mm) Diameter

                         7/16”(11mm) Long

push button switch/FE-A1228
push button switch/door light switch/FE-A1229/universal type
push button switch/door light switch/drawing of FE-A1229

Door Light Switch

2 Position (Off)-On

Copper Contacts

Universal type

Panel Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Copper Contacts

Rating : 11Amps @ 12Volts DC / 2.5Amps @ 24Volts DC

Replaces Lucas Part No. SPB106

Applications : AC Cobra / Jaguar / David Brown

push button switch/panel switch/FE-A1230/SPST/Lucas SPB106/AC Cobra/Jaguar/David Brown
push button switch/drawing of FE-1230

FE-A1228

FE-A1229

FE-A1230

Panel Switch

2 Position Off-(On)

2 Terminals

Rating : 11Amps @ 12Volts DC

Replaces Lucas Part No. SPB105

Applications : Jaguar

push button switch/panel switch/FE-A1231/Lucas SPB105/Jaguar
push button switch/panel switch/drawing of FE-A1231

FE-A1231

FE-A1232

push button switch/FE-A1232/SPST

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 5/8”(15.87mm) Diameter

push button switch/drawing of FE-A1232
push button switch/FE-A1233/SPST

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 3Amps @ 125Volts / 1Amps @ 250Volts

push button switch/door switch for interior light/FE-A1234/Volkswagens VWC-113-947-561-B

Door Switch for Interior Light

2 Position (Off)-On

Copper Contacts

Applications : Volkswagens VWC-113-947-561-B

push button switch/door switchfor interior light/drawing of FE-A1234

FE-A1233

FE-A1234

​Horn Switch for forklift

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 3Amps @ 125Volts / 1Amps @ 250Volts

Horn switch for Forklift

push button switch/wire set/FE-A2201
push button switch/wire set/drawing of FE-A2201

FE-A2201

push button switch/FE-A2202/waterproof rubber cover

Same as FE-A1226 but with wire

2 Position Off-(On)

2 Screw terminals

Copper Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 5/8”(15.87mm) Diameter

With Rubber Cover and Mounting Nut

FE-A2202
