2 Blade terminals
Nickel plated Bronze Contacts
Rating : 6-24Volts DC
Without Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1002
2 Screw terminals
Bronze Contacts
Rating : 6-24Volts DC
Without Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1001
PILOT LAMP
Dimemsions in m/m
2 Screw terminals
Bronze Contacts
Rating : 6-24Volts DC
Without Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1004
2 Blade terminals
Tin plated Bronze Contacts
Rating : 50Amps @ 12Volts DC
With Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1003
2 Blade terminals
Bronze Contacts
Rating : 120 / 220Volts AC
With Neon Lamp
Lens 5 Colors : Red / Amber / Green / Blue / Clear
2 Blade terminals
Bronze Contacts
Rating : 12 / 24Volts DC
With Bulb
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1008
FE-A1007
2 Blade terminals
Bronze Contacts
Rating : 12 / 24Volts DC
With Bulb
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1006
2 Blade terminals
Bronze Contacts
Rating : 12 / 24Volts DC
With Bulb
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1005
2 Blade terminals
Bronze Contacts
Rating : 12 / 24Volts DC
With LED
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1013
2 Terminals
Bronze Contacts
Rating : 12 / 24Volts DC
With LED
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1012
2 Terminals
Bronze Contacts
Rating : 12 / 24Volts DC
With LED
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1011
2 Blade terminals
Bronze Contacts
Rating : 12 / 24Volts DC
With Bulb
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1009
Same as FE-A1014 but with wire
Rating : 12 / 24Volts DC
With LED
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1014
2 Blade terminals
Bronze Contacts
Rating : 12 / 24Volts DC
With LED
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1014K
2 Blade terminals
Bronze Contacts
Rating : 12 / 24Volts DC
Without Bulb
Lens 3 Colors : Red / Amber / Green
FE-A1015
FE-A1016
2 Blade terminals
Bronze Contacts
Rating : 6-24Volts DC
With LED
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1017
2 Blade terminals
Bronze Contacts
Rating : 6-24Volts DC
With LED
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1018
2 Blade terminals
Bronze Contacts
Rating : 6-24Volts DC
With LED
Lens 5 Colors : Red / Amber / Green / Blue / Clear
2 Screw terminals
Bronze Contacts
Rating : 6-24Volts DC
With Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1020
2 Screw terminals
Bronze Contacts
Rating : 6-24Volts DC
With Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1019
2 Screw terminals
Bronze Contacts
Rating : 6-24Volts DC
With Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1021
2 Blade terminals
Bronze Contacts
Rating : 12 / 24Volts DC
With Bulb
Lens 5 Colors : Red / Amber / Green / Blue / Clear
FE-A1010
FE-A1022
2 Wire
Rating : 12 / 24Volts DC
With Bulb
Lens 5 Colors : Red / Amber / Green / Blue / Clear
2 Blade terminals
Silver plated Bronze Contacts
Rating : 6-24Volts DC
Without Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1025
2 Blade terminals
Silver plated Bronze Contacts
Rating : 6-24Volts DC
Without Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1024
2 Blade terminals
Bronze Contacts
Rating : 6-24Volts DC
Without Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1023
FE-A1029
FE-A1028
FE-A1027
2 Blade terminals
Silver plated Bronze Contacts
Rating : 6-24Volts DC
Without Bulb
Lens 4 Colors : Red / Amber / Green / Blue
FE-A1026
2 Blade terminals
Rating : 12-24Volts DC
With Bulb
Lens 2 Colors : Red / Amber / Green / Clear
2 Blade terminals
Silver plated Bronze Contacts
Rating : Bulb 15W 14Volts DC / LED 12Volts DC
With Bulb / LED
Lens 5 Colors : Red / Amber / Green / Blue / Clear
2 Blade terminals
Bronze Contacts
Lens 4 Colors : Red / Amber / Green / Blue
2 Position On-(Off)
2 Blade terminals
Copper Contacts
Applications : Fiat
FE-A1308
FE-A1307
Throttle Pull Switch
2 Position Off-(On)
2 Terminals
Copper Contacts
Rating : 10Amps @ 12Volts DC
FE-A1306
2 Position On-(Off)
2 Blade terminals
Copper Contacts
Applications : Fiat
FE-A1302
2 Position Off-(On)
2 Screw terminals
Bronze Contacts
Rating : 10Amps @ 12Volts DC
Applications : Merit No. 431300
FE-A1301
STOP LIGHT SWITCH
2 Position On-(Off)
2 Blade terminals
Copper Contacts
Applications : Ford / Chrysler / IHC
Dimemsions in m/m
FE-A1303
Door / Momentary Switch
2 Position On-(Off)
2 Terminals
2 Male Bullet Connectors
Applications : Toyota / Mitsubishi
FE-A1304
Door / Momentary Switch
2 Position On-(Off)
2 Terminals
2 Male Bullet Connectors
Applications : Datsun / Daihatsu / Subaru
FE-A1305
Door / Momentary Switch
2 Position On-(Off)
2 Terminals with Male Housing
Applications : Toyota
HEAD LIGHT SWITCH
FE-A1801
3 Position Off-On-On
5 Screw terminals
Iron Contacts
Rating : 15Amps @ 12Volts DC
Universal Type
FE-A1802
3 Position Off-On-On
4 Screw terminals
Iron Contacts
Rating : 15Amps @ 12Volts DC
Universal Type
3 Position Off-On-On
5 Screw terminals
Iron Contacts
Rating : 15Amps @ 12Volts DC
Universal Type
FE-A1803
3 Position Off-On-On
4 Screw terminals
Iron Contacts
Rating : 15Amps @ 12Volts DC
Universal Type
FE-A1804
3 Position Off-On-On
5 Screw terminals
Iron Contacts
Rating : 30Amps fuse 6 Volts DC
15Amps fuse 12Volts DC
Universal Type
FE-A1805
3 Position Off-On-On
4 Screw terminals
Brass Contacts
Rating : 15Amps @ 24Volts DC
Applications : Mercedes Benz
FE-A1806
3 Position Off-On-On
5 Screw terminals
Brass Contacts
Rating : 15Amps @ 24Volts DC
Mounting Stem : 15mm Long / 10mm Diameter
FE-A1807
2 Position Off-On
2 Screw terminals
Iron Contacts
Rating : 15Amps @ 12Volts DC
Universal Type
FE-A1808
FE-A1809
Push pull headlamp dashboard switch
with circuit breaker and rheostat
3 Position Off-On-On
5 Screw terminals / 2 Stud terminals
Iron Contacts
Mounting Stem : 3/8” Long / 3/8” Diameter
FE-A1810
FE-A1811
3 Position Off-On-On
4 Screw terminals
Iron Contacts
Rating : 30Amps @ 12Volts DC
Black plastic actuator with Headlamp symbol imprint
FE-A1815
4 Position Off-On-On-On
5 Screw terminals
Iron Contacts
Rating : 30Amps @ 12Volts DC
Black plastic actuator with Headlamp symbol imprint
FE-A1816
Single Pole Single Throw Switch
2 Position Off-On
2 Screw terminals
Copper Contacts
Rating : 75Amps @ 6-28Volts DC
Mounting Stem : 5/8” Long / 15/32’ Diameter
Chrome Plated Metal Knob
FE-A1817
3 Position Off-On-On
Off-Park-Headlamps function
4 Screw terminals
Copper Contacts
Rating : 10Amps @ 12Volts DC
5Amps @ 24Volts Dc
Black plastic actuator with “LIGHTS” imprint
Dimemsions in m/m
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 30Amps @ 12Volts DC
Black plastic actuator with Headlamp symbol imprint
Universal Type
FE-A1902
PUSH PULL SWITCH
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 3/4” (19mm)Long / 5/16” Diameter
With small knob
FE-A1903
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 1/2” (13mm)Long / 5/16” Diameter
With small knob
FE-A1904
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 5/16” (8mm)Long / 5/16” Diameter
With small knob
Dimemsions in m/m
FE-A1905
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 3/4” (19mm)Long / 5/16” Diameter
With big knob
FE-A1906
FE-A1907
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 1/2” (13mm)Long / 5/16” Diameter
With big knob
FE-A1909
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 5/16” (8mm)Long / 5/16” Diameter
With big knob
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 5/16” (8mm)Long / 5/16” Diameter
With big knob
FE-A1910
2 Position Off-On
2 Blade terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 1/2” (13mm)Long / 15/32” Diameter
With big knob
FE-A1911
2 Position Off-On
2 Blade terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 5/16” (8mm)Long / 5/16” Diameter
With big knob
FE-A1912
2 Position Off-On
2 Screw terminals
Bronze Contacts
Rating : 6Amps @ 12Volts DC
Mounting Stem : 5/16” (8mm)Long / 5/16” Diameter
With big knob and fog light mark plate
FE-A1913
FE-A1914
2 Position Off-On
2 Screw terminals
Iron Contacts
Mounting Stem : 5/8” (16mm)Long / 1/2” Diameter
Chrome plated Integral knob
2 Position Off-On
2 Wire
2 Male Bullet Connectors
CABLE SWITCH
FE-A2101
Cable Switch
7 Blade terminals
Bronze Contacts
Replaces Lucas Pakan
FE-A2107
Cable Switch
3 Wires(Red / Black / Gray)
Wires are installs into the bottom of the
steering column lock assembly
Applications : Volkswagen
FE-A2108
Cable Switch
5 Blade terminals
Bronze Contacts
Replaces Lucas Part No. 35289
Applications : Land Rover PRC2735
Dimemsions in m/m
PRESSURE SWITCH
Dimemsions in m/m
FE-A2301
2 Stud terminals
Bronze Contacts
Mounting Stem : M15xP1.5 Thread
FE-A2302
FE-A2303
FE-A2304
FE-A2305
2 Stud terminals
Bronze Contacts
Mounting Stem :9/16”-18G Thread
2 Stud terminals
Copper Contacts
Mounting Stem : 1/2”-19G Thread
For low pressure applications
2 Stud terminals
Copper Contacts
Mounting Stem : 1/2”-19G Thread
Brass housing
2 Terminals
Copper Contacts
Mounting Stem : M16xP1.5 Thread
CIRCUIT BREAKER
Dimemsions in m/m
FE-A2501
Automatic reset circuit breaker
2 Stud terminals
Rating : 20 / 30 / 40 / 50Amps @ 12Volts
Zinc plated metal cover without bracket
FE-A2502
Automatic reset circuit breaker
2 Stud terminals
Rating : 10 / 15 / 20 / 25 / 30 / 40 / 50Amps @ 12Volts
Zinc plated metal cover with horizontal bracket
FE-A2503
Automatic reset circuit breaker
2 Blade terminals
Rating : 20 / 30 / 40 Amps @ 12Volts
Zinc plated metal cover
FE-A2701
ROCKER SWITCH
Single Pole Double Throw Switch
3 Position Off-On-On
3 Blade terminals
Copper Contacts
Rating : 15Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Lights symbol imprint
FE-A2702
Single Pole Double Throw Switch
3 Position Off-On-On
3 Blade terminals
Copper Contacts
Rating : 15Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Washer symbol imprint
FE-A2703
FE-A2704
Single Pole Double Throw Switch
3 Position Off-On-On
3 Blade terminals
Copper Contacts
Rating : 15Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Fuel Meter symbol imprint
Single Pole Double Throw Switch
3 Position Off-On-On
3 Blade terminals
Copper Contacts
Rating : 25Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Heater Fan symbol imprint
FE-A2705
Single Pole Double Throw Switch
3 Position Off-On-On
3 Terminals
Copper Contacts
Rating : 25Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Lights symbol imprint
FE-A2706
FE-A2707
Single Pole Single Throw Switch
2 Position Off-On
2 Terminals
Copper Contacts
Rating : 25Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Lights symbol imprint
Single Pole Single Throw Switch
2 Position Off-On
2 Terminals
Copper Contacts
Rating : 25Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With symbol imprint
FE-A2708
Single Pole Double Throw Switch
3 Position Off-On-On
3 Terminals
Copper Contacts
Rating : 25Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Heater Fan symbol imprint
Dimemsions in m/m
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Copper Contacts
Rating : 15Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Fuel Meter symbol imprint
FE-A2709
FE-A2710
Single Pole Double Throw Switch
3 Position Off-On-On
3 Blade terminals
Copper Contacts
Rating : 15Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Heater Fan symbol imprint
FE-A2711
FE-A2712
Single Pole Single Throw Switch
2 Position Off-(On)
2 Terminals
Copper Contacts
Rating : 25Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Washer symbol imprint
3 Position On-On-On
5 Terminals
Copper Contacts
Rating : 25Amps @ 12Volts DC
Mounting : L 38mm / W 28mm
With Wiper symbol imprint
FE-A2713
Single Pole Single Throw Switch
2 Position Off-On
3 Blade Terminals
Rating : 10Amps @ 12Volts DC
Rocker Switch with Panel Combination
With Bulb
4 Colors : Red / Amber / Green / Blue
FE-A2714
Lighted Switch Kit
2 Position Off-On
Rating : 20Amps @ 12Volts DC
With Bulb
FE-A2715
Rocker Switch Kit
3 Position On-Off-On
Rating : 16Amps @ 125Volts AC / 10Amps @ 250Volts AC
FE-A2716
FE-A2717
FE-E2701
FE-E2701C
FE-E2702
FE-E2702C
FE-E2705
FE-E2709
FE-A2719
Single Pole Single Throw Switch
3 Position Off-On
3 Blade terminals
Copper Contacts
Rating : 16Amps @ 12Volts DC
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Copper Contacts
Single Pole Single Throw Switch
2 Position Off-On
3 Screw terminals
Rating : 16Amps @ 12Volts DC
2 Colors : Red / Amber
Single Pole Single Throw Switch
2 Position Off-On
2 Pins
Single Pole Single Throw Switch
Same as FE-E2701 but with Silicone Cover
2 Position Off-On
2 Pins
Single Pole Single Throw Switch
2 Position Off-On
2 Blade terminals
Rating : 12Volts DC
4 Colors : Red / Amber / Green / Black
FE-E2702M 2 Position Off-(On)
Single Pole Single Throw Switch
Same as FE-E2702 but with Silicone Cover
2 Position Off-On
2 Pins
Single Pole Single Throw Switch
2 Position Off-On
2 Pins
3P Single Pole Single Throw Switch
2 Position Off-On(With LED) / Off-(On)
Rating : 12Volts DC
2 Pins
FE-A272992A2G0
Single Pole Single Throw Switch
2 Position On-Off
Contact resistance : 20mΩ max. (initial)
Insulation resistance : 100mΩ min. (at 500V DC)
Dielectric strength : 1500V AC 50/60 Hz for 1 min.
Service life : Mechanically-100000 operations min.
Electrically-30000 operations min.
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
Single Pole Single Throw Switch
2 Position (On)-Off
Contact resistance : 20mΩ max. (initial)
Insulation resistance : 100mΩ min. (at 500V DC)
Dielectric strength : 1500V AC 50/60 Hz for 1 min.
Service life : Mechanically-100000 operations min. Electrically-30000 operations min.
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
FE-A272992A2M1
FE-A272993A2G101LA/B/R/G
Single Pole Single Throw Switch
2 Position On-Off
Contact resistance : 20mΩ max. (initial)
Insulation resistance : 100mΩ min. (at 500V DC)
Dielectric strength : 1500V AC 50/60 Hz for 1 min.
Service life : Mechanically-100000 operations min.
Electrically-30000 operations min.
Rating : 20Amps @ 12Volts DC
With 4 colors LED lamp : Red , Amber , Blue , Green
FE-A272993A2M1G101LB/R
Single Pole Single Throw Switch
2 Position (On)-Off
Contact resistance : 20mΩ max. (initial)
Insulation resistance : 100mΩ min. (at 500V DC)
Dielectric strength : 1500V AC 50/60 Hz for 1 min.
Service life : Mechanically-100000 operations min. Electrically-30000 operations min.
Rating : 20Amps @ 12Volts DC
With 4 colors LED lamp : Red , Blue
FE-A272993A3G0
Single Pole Double Throw Switch
3 Position On-Off-On
Contact resistance : 20mΩ max. (initial)
Insulation resistance : 100mΩ min. (at 500V DC)
Dielectric strength : 1500V AC 50/60 Hz for 1 min.
Service life : Mechanically-100000 operations min. Electrically-30000 operations min.
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
FE-A272994A3G11-2LRA
Single Pole Double Throw Switch
3 Position On-Off-On
Contact resistance : 20mΩ max. (initial)
Insulation resistance : 100mΩ min. (at 500V DC)
Dielectric strength : 1500V AC 50/60 Hz for 1 min.
Service life : Mechanically-100000 operations min. Electrically-30000 operations min.
Rating : 20Amps @ 12Volts DC
With 2 LED lamp : Red , Amber
FE-A272996A3G0
Double Pole Double Throw Switch
3 Position On-Off-On
Contact resistance : 20mΩ max. (initial)
Insulation resistance : 100mΩ min. (at 500V DC)
Dielectric strength : 1500V AC 50/60 Hz for 1 min.
Service life : Mechanically-100000 operations min. Electrically-30000 operations min.
Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
Double Pole Double Throw Switch
3 Position On-Off-On
Contact resistance : 20mΩ max. (initial)
Insulation resistance : 100mΩ min. (at 500V DC)
Dielectric strength : 1500V AC 50/60 Hz for 1 min.
Service life : Mechanically-100000 operations min. Electrically-30000 operations min.
Rating : 20Amps @ 12Volts DC
With 2 LED lamp : Red , Amber
FE-A272996A3G11-2LRA
WINDOW SWITCH
FE-A3701
5 Prong switch direct
Copper Contacts
Chrome plated housing
1 Button
Applications : Delco
FE-A3702
6 Prong switch direct
Copper Contacts
Chrome plated housing
2 Buttons
Dimemsions in m/m
FE-A3704
Power Window Switch
5 Blade terminals
Copper Contacts
Rating : 12-24Volts DC
FE-A3704A
Window Rocker Switch
5 Pins
FE-A3704A : Non-Light
FE-A3704A-1 : With 12V DC Light
FE-A3709
FE-A4602
FE-A4901
Lock Gas Cap , 2 Keys
Suits classic car
Chrome plated Zinc die cast
Applications : Chevrolet
FE-A4603-BK . FE-A4603GRAY
Car Cigarette Lighter
With button(FE-E2709)
Same as FE-A4602 but extension cable set
Rating : 12Volts DC
Cable set 2 Colors : Black / Gray
5 Prong switch direct
Nickel plated Copper Contacts
Zinc housing
2 Buttons
FE-A4601
Car Cigarette Lighter
Without button
Car Cigarette Lighter
With button(FE-E2709)
Rating : 12Volts DC
FE-A4701
TURN SIGNAL SWITCH
Turn Signal Switch for truck
For use on vehicles having combination stop and
turn signal lamps and requiring brake light circuit
3 Positions
Chrome plated Zinc die cast
Die cast handle
Long lasting contacts extend switch life
Heavy Duty wiring 7-wire harness
Universal Type
Dimemsions in m/m
FE-A4702
Turn Signal Switch for truck
For use on vehicles having combination stop and
turn signal lamps and requiring brake light circuit
3 Positions
Chrome plated Zinc die cast
Die cast handle
Long lasting contacts extend switch life
Heavy Duty wiring 7-wire harness
Universal Type
FE-A4703
Turn Signal Switch for truck
For use on vehicles having combination stop and turn signal lamps and requiring brake light circuit
3 Positions
Zinc die cast
Die cast handle
Long lasting contacts extend switch life
Heavy Duty wiring 7-wire harness
Universal Type
FE-A4705
FE-A4705-1
Turn Signal Switch Wiring
8 Wires
Wiring harness
Turn signal-canceling camera
Built-in horn switch
Applications : Ford
Turn Signal Repair
2 Wires
Applications : Ford
FE-A4706
Turn Signal Switch
6 wires with terminals
