ignition starter switch/FE-A1101/key set/universal type/Delco U-1403

4 Position ACC-Off-On-Start , 2 Keys

4 Stud terminals

Copper Contacts

Rating : 30Amps @ 12Volts DC

Mounting Stem : 7/16” Long / 3/4” Diameter

                        1 1/8” Mounting Nut

Universal Type

Key is only removable in the Off position

Applications : Delco U-1403

FE-A1101

FE-A1104

​IGNITION STARTER SWITCH

Single Throw Ignition Starter Switch

2 Position Off-On , 2 Keys

2 Terminals

Bronze Contacts

Rating : 15Amps @ 6Volts DC / 10Amps @ 12Volts DC

Mounting Stem : 3/4” Long / 3/4” Diameter

                        1/8” Mounting Nut

Universal Type

Key is only removable in the Off position

Application : Delco U-1400

ignition starter switch/FE-A1104/key set/universal type/Delco U-1400

Dimemsions in m/m

ignition starter switch/drawing of FE-A1101
ignition starter switch/drawing of FE-A1104

FE-A1105

FE-A1106

Double Throw Ignition Starter Switch

3 Position On-Off-On , 2 Keys

3 Terminals

Bronze Contacts

Rating : 15Amps @ 6Volts DC / 10Amps @ 12Volts DC

Mounting Stem : 3/4” Long / 3/4” Diameter

                        1 1/8” Mounting Nut

Universal Type

Key is only removable in the Off position

Applications : Delco U-1402

Switch Lock from national cabinet lock

2 Position , 2 Keys

2 Blade terminals

Copper Contacts

FE-A1109

3 Position Off-On-Start , 2 Keys

5 Blade terminals

Copper Contacts

Key is only removable in the Off position

Replaces Lucas Part No.31973K4183 , 31973K4287

Applications : Land Rover

FE-A1110

4 Position ACC-Off-On-Start , 2 Keys

4 Screw terminals

Bronze Contacts

Key is only removable in the Off position

Applications : Toyota-RS RK-FJ-RA

              Part No.221011-5200 ISC-4

FE-A1111

3 Position Off-On-Start , 2 Keys

3 Screw terminals

Copper Contacts

Universal Type

Key is only removable in the Off position

Applications : Mitsubishi A-10 / Mini Car 300 / Colt 600

FE-A1112

4 Position ACC-Off-On-Start , 2 Keys

4 Screw terminals

Copper Contacts

Key is only removable in the Off position

Applications : Toyota ISC-7 Part No. 221035-5200

FE-A1118

4 Position ACC-Off-On-Start , 2 Keys

5 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Isuzu KB-20 / Mitsubishi Colt L-300

FE-A1119

4 Position ACC-Off-On-Start , 2 Keys

5 Blade terminals

Nickel plated Iron Contacts

Universal Type

Key is only removable in the Off position

Applications : Dutsun 520 , 620 / Nissan

FE-A1120

4 Position ACC-Off-On-Start , 2 Keys

4 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Dutsun Sunny 120Y , B310

FE-A1121

3 Position Off-On-Start , 2 Keys

3 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Dutsun Sunny 120Y , B310

ignition starter switch /FE-A1105/key set/universal type/Delco U-1402
ignition starter switch/FE-A1106/key set/national cabinet lock
ignition starter switch/FE-A1109/key set/Lucas/Land Rover
ignition starter switch/FE-A1110/key set/Toyota 221011-5200 ISC-4
ignition starter switch/FE-A1111/key set/universal type/Mitsubishi A-10/Mini car 300/Colt 600
ignition starter switch/FE-A1112/key set/Toyota ISC-7 221035-5200
ignition starter switch/FE-A1118/key set/Isuzu KB-20/Mitsubishi Colt L-300
ignition starter switch/FE-A1119/key set/universal type/Dutsun 520,620/Nissan
ignition starter switch/FE-A1120/key set/Dustsun Sunny 120Y,B310
ignition starter switch/FE-A1121/key set/Dustsun Sunny 120Y,B310
ignition starter switch/FE-A1116/key set/Toyota ISC-9 221067-5200
igition starter switch/FE-A1115/key set/Suzuki ST-20,ST-90/Jeep/Pick up/Mini bus
ignition stater switch/FE-A1114/key set/universal type/Toyota ISC-5R 221126-5201

4 Position ACC-Off-On-Start , 2 Keys

4 Blade terminals(Plug in type)

Copper Contacts

Key is only removable in the Off position

Applications : Toyota ISC-9 Part No. 221067-5200

FE-A1116

3 Position Off-On-Start , 2 Keys

3 Screw terminals

Copper Contacts

Key is only removable in the Off position

Applications : Suzuki ST-20 , ST-90 / Jeep / Pick up / Mini Bus

FE-A1115

3 Position Off-On-Start , 2 Keys

3 Screw terminals

Copper Contacts

Universal Type

Key is only removable in the Off position

Applications : Toyota ISC-5R Part No. 221126-5201

FE-A1114

ignition starter switch/drawing of FE-A1119
ignition starter switch/draing of FE-A1120
ignition starter switch/drawing of FE-A1109
ignition starter switch/drawing of FE-A1121
ignition starter switch/drawing of FE-A1105
ignition starter switch/drawing of FE-A1106
ignition starter switch/drawing of FE-A1110
ignition starter switch/drawing of FE-A1111
ignition starter switch/drawing of FE-A1112
ignition starter switch/drawing of FE-A1114
ignition starter switch/drawing of FE-A1115
ignition starter switch/drawing of FE-A1116
ignition starter switch/draing of FE-A1118

4 Position ACC-Off-On-Start , 2 Keys

6 Screw terminals

Bronze Contacts

Rating : 12Volts

Key is only removable in the Off position

Applications : Isuzu Bus&Truck SS-54-3

FE-A1123

4 Position ACC-Off-On-Start , 2 Keys

6 Screw terminals

Copper Contacts

Key is only removable in the Off position

Applications : Toyota ISC-8R Part No.

                   222124-5200 / Mitsubishi / Hino Truck&Bus

FE-A1124

4 Position ACC-Off-On-Start , 2 Keys

6 Screw terminals

Copper Contacts

Rating : 24Volts

Universal Type

Key is only removable in the Off position

Applications : HKT SI-05 / Mitsubishi

FE-A1125

FE-A1126

4 Position ACC-Off-On-Start , 2 Keys

6 Screw terminals

Copper Contacts

FE-A1124 with wire & connector

Key is only removable in the Off position

Applications : Toyota ISC-24

Ignition Starter Switch with lock cylinder and Keys

4 Position ACC-Off-On-Start , 2 Keys

11 Blade terminals

Iron Contacts

Rating : 12Volts

Key is only removable in the Off position

Applications : Delco / IHC / International / Jeep

FE-A1127

ignition starter switch/FE-A1123/key set/Isuzu Bus&Truck SS-54-3
ignition starter switch/FE-A1124/key set/Toyota ISC-8R 222124-5200/Mitsubishi/Hino Truck&Bus
ignition starter swtch/FE-A1125/ket set/universal type/HKT SI-05/Mitsubishi
ignition starter switch/FE-A1127/ket set/Delco/IHC/Jeep
ignition starter switch/drawing of FE-A1123
ignition starter switch/drawing of FE-A1127
ignition startr switch/drawing of FE-A1124
ignition starter switch/drawing of FE-A1125
ignition starter swich/drawing of FE-A1126
ignition starter swich/FE-A1126/key set/Toyota ISC-24

Ignition Starter Switch with coded tumbler lock

3 Position , 2 Keys

4 Screw terminals

Bronze Contacts

Rating : 15Amps @ 12Volts DC

Mounting Stem : 13/16”-24 Thread

O-ring sealed at stem

Key is only removable in the Off position

FE-A1133

3 Position Off-On-Start , 2 Keys

5 terminals

Copper Contacts

Universal Type

Key is only removable in the Off position

Applications : Renault

FE-A1131

3 Position Off-On-Start , 2 Keys

7 Blade terminals

Copper Contacts

Rating : 12-24Volts

Key is only removable in the Off position

Replaces Lucas Part NO.35288

Applications : Land Rover

FE-A1130

3 Position Off-On-Start , 2 Keys

3 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Volkswagen

FE-A1129

3 Position Off-On-Start , 2 Keys

3 Blade terminals

Copper Contacts

Key is only removable in the Off position

Applications : Volkswagen

FE-A1128

ignition starter switch/FE-A1129/key set/Volkswagen
igntion starter switch/FE-A1130/key set/Lucas 35288/Land Rover
ignition starter switch/FE-A1131/key set/universal type/Renault
ignition starter switch/FE-A1133/key set/coded tumbler lock
ignition starter switch/FE-A1128/key set/Volkswagen
Ignition starter switch/drawing of FE-A1128
ignition starter switch/drawing of FE-A1129
ignition starter switch/drawing of FE-A1131
ignition starter switch/drawing of FE-A1130
ignition starter switch/drawing of FE-A1133


PUSH BOTTON SWITCH

FE-A1201

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 25Amps @ 6Volts DC / 15Amps @ 12Volts DC

Mounting Stem : 5/8” Diameter

Universal type

Applications : Chrysler / IHC

push button switch/FE-A1201/SPST/Chrysler/IHC
push button switch/drawing of FE-A1201

Dimemsions in m/m

Starter Button Switch

2 Position Off-(On)

1 Terminal

Iron / Bronze Contact

Rating : 15Amps @ 6Volts DC

           10Amps @ 12Volts DC

            6Amps @ 24Volts DC

FE-A1202

push button switch/FE-A1202
push button switch/drawing of FE-A1202
push button switch/door jamb switch/FE-A1203/SPST/universal type/Chrysler 882943

FE-A1203

Door Jamb Switch

Single Pole Single Throw

2 Position (Off)-On

2 Screw terminals

Copper Contacts

Rating : 5Amps @ 12Volts DC

Mounting Stem : 1 3/8” and 2 1/16” on centers

Universal type / insulated

Applications : Chrysler 882943

FE-A1204

Horn Button Switch

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 5Amps @ 12Volts DC

Chrome surface

FE-A1205

Horn Button Switch

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 5Amps @ 12Volts DC

Chrome surface

push button switch/horn button switch/FE-A1204
push button switch/horn button switch/FE-1205
push button switch/horn button switch/drawing of FE-A1205
push buttn switch/door jamb switch/drawing of FE-A1203
push button switch/horn button switch/drawing of FE-A1204
push button switch/horn button switch/drawing of FE-A1204

FE-A1206

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Applications : Merit No. 201000

push button switch/FE-A1206/SPST/Merit 20100
push button switch/drawing of FE-A1206

Starter Button Switch

Single Pole Single Throw

Same as FE-A1206 but using heat resistant material

2 Position Off-(On)

2 Screw terminals

Silver Plated Bronze Contacts

Rating : 30Amps @ 12Volts DC

FE-A1206S

push button switch/FE-A1206S/SPST/heat resistant material
push button switch/drawing of FE-A1206S

FE-A1207

Starter Button Switch

Single Pole Single Throw

Same as FE-A1206 but with Waterproof Rubber Cover

2 Position Off-(On)

2 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

Applications : Merit 201000

FE-A1213

FE-A1212

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Silver Plated Bronze Contacts

Rating : 15Amps @ 125Volts AC

            / 10Amps @ 250Volts AC

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 25Amps @ 6Volts DC

            / 15Amps @ 12Volts DC

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Copper Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 15.87 m/m Long / 5/8” Diameter

Replaces Pollak Part No. 21-360

Applications : Delco 1996097

FE-A1211

FE-A1210

2 Position Off-(On)

Single Pole Single Throw

2 Blade terminals

Silver Plated Bronze Contacts

Rating : 15Amps @ 12Volts DC

Mounting Stem : 7/8” (22.2mm) Diameter

FE-A1209

FE-A1214

Heavy Duty Push Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Copper Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 5/8”-32 Thread

Chrome plated face nut

FE-A1215

Door Jamb Switch

Single Pole Single Throw

2 Position (Off)-On

2 Screw terminals

Bronze Contacts

Applications : Delco 1972532 / Ford 1965-79 / Mercury 1965-79

FE-A1216

Starter Button Switch

2 Position Off-(On)

1 snap-in terminal

Bronze Contact

Rating : 15Amps @ 6Volts DC

           10Amps @ 12Volts DC

            6Amps @ 24Volts DC

FE-A1219

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Copper Contacts

Rating : 15Amps @ 120Volts AC

            10Amps @ 240Volts AC

push button switch/FE-A1209/SPST
push button switch/FE-A1210/SPST/Pollak 21-360/Delc 1996097
push button switch/FE-A1211/SPST
push button switch/FE-A1212/SPST
push button switch/FE-A1213/SPST/Merit
heavy duty push button switch/FE-A1214/SPST
push button switch/door jamb switch/FE-A1215/SPST/Delco 1972532/Ford 1965-79/Mercury 1965-79
push button switch/FE-A1216
push button switch/FE-A1219/SPST
push button switch/drawing of FE-A1207
push button switch/drawing of FE-A1209
push button switch/drawing of FE-A1210
push button switch/drawing of FE-A1211
push button switch/drawing of FE-A1212
heavy duty push button switch/drawing of FE-A1214
push button switch/drawing of FE-A1216
push button switch/drawing of FE-A1219
push button switch/drawing of FE-A1213
push button switch/FE-A1207/SPST/waterproof rubber cover
push button switch/door jamb switch/drawing of FE-1215

FE-A1219C

FE-A1220

FE-A1220C

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 15Amps @ 12Volts DC

FE-A1222

Starter Button Switch

Single Pole Single Throw

Same as FE-A1201 but with Rubber Cap

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Rating : 25Amps @ 6Volts DC / 15Amps @ 12Volts DC

Mounting Stem : 5/8” Diameter

Universal type

Applications : Chrysler / IHC

push button switch/FE-A1220C/SPST/waterproof rubber cover
push button switch/FE-A1222/SPST/waterproof rubber cover/universal type/Chrysler/IHC
push button switch/FE-A1220/SPST
push button switch/FE-A1219C/SPST/waterproof/sikicone cover
push button switch/drawing of FE-A1219C
push button witch/drawing of FE-A1220
push button switch/drawing of FE-A1220C
push button switch/drawing of FE-A1222

Starter Button Switch

Single Pole Single Throw

Same as FE-A1219 but with Silicone Cover

2 Position Off-(On)

2 Blade terminals

Copper Contacts

Rating : 15Amps @ 120Volts AC

           10Amps @ 240Volts AC

Starter Button Switch

Single Pole Single Throw

Same as FE-A1220 but with Rubber Cover

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 15Amps @ 12Volts DC

FE-A1221

Starter Button Switch

2 Position Off-(On)

2 Wires (150mm)

Rating : 3Amps @ 250Volts AC

6Amps @ 125Volts AC

Button : Brass with Nickel Plated

push button swich/FE-A1221
push button switch/drawing of FE-A1221

FE-A1223

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Silver Plated Bronze Contacts

Rating : 15Amps @ 125Volts AC / 10Amps @ 250Volts AC

FE-A1224

Door Contact Switch

Single Pole Single Throw

2 Position (Off)-On

2 Blade terminals

Copper Contacts

Rating : 15Amps @ 12Volts DC

Push Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Bronze Contacts

Rating : 20Amps @ 12Volts DC

FE-A1225

FE-A1226

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Screw terminals

Copper Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 5/8”(15.87mm) Diameter

With Rubber Cover and Mounting Nut

Replaces Pollak Part No. 21-360

Applications : Delco 1996097

FE-A1228

Push Button Switch

2 Position Off-(On)

2 Screw terminals

Rating : 25Amps @ 12Volts DC

Mounting Stem : 15/32”(12mm) Diameter

                         7/16”(11mm) Long

Door Light Switch

2 Position (Off)-On

Copper Contacts

Universal type

FE-A1229

FE-A1230

Panel Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Copper Contacts

Rating : 11Amps @ 12Volts DC / 2.5Amps @ 24Volts DC

Replaces Lucas Part No. SPB106

Applications : AC Cobra / Jaguar / David Brown

FE-A1232

FE-A1234

FE-A1233

push button switch/FE-A1223/SPST
push button switch/door contact switch/FE-A1224/SPST
push button switch/FE-A1225/SPST
push button switch/FE-A1228
push button switch/FE-A1232/SPST
push button switch/FE-A1233/SPST
push button switch/door switch for interior light/FE-A1234/Volkswagens VWC-113-947-561-B
push button switch/FE-A1226/SPST/waterproof rubber cover/Pollak 21-360/Delco 1996097
push button switch/door light switch/FE-A1229/universal type
push button switch/panel switch/FE-A1230/SPST/Lucas SPB106/AC Cobra/Jaguar/David Brown
push button switch/drawing of FE-A1223
push button switch/drawing of FE-A1224
push button switch/drawing of FE-1225
push butto switch/drawing of FE-A1226
push button switch/drawing of FE-A1228
push button switch/door light switch/drawing of FE-A1229
push button switch/drawing of FE-1230
push button switch/drawing of FE-A1232
push button switch/drawing of FE-A1233
push button switch/door switchfor interior light/drawing of FE-A1234

FE-A1231

Panel Switch

2 Position Off-(On)

2 Terminals

Rating : 11Amps @ 12Volts DC

Replaces Lucas Part No. SPB105

Applications : Jaguar

push button switch/panel switch/FE-A1231/Lucas SPB105/Jaguar
push button switch/panel switch/drawing of FE-A1231

Starter Button Switch

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 5/8”(15.87mm) Diameter

Single Pole Single Throw

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 3Amps @ 125Volts / 1Amps @ 250Volts

Door Switch for Interior Light

2 Position (Off)-On

Copper Contacts

Applications : Volkswagens VWC-113-947-561-B

FE-A2201

FE-A2202

push button switch/wire set/FE-A2201
push button switch/FE-A2202/waterproof rubber cover
push button switch/drawing of FE-A2202
push button switch/wire set/drawing of FE-A2201

Same as FE-A1233 but with wire set

2 Position Off-(On)

2 Blade terminals

Bronze Contacts

Rating : 3Amps @ 125Volts / 1Amps @ 250Volts

Same as FE-A1226 but with wire

2 Position Off-(On)

2 Screw terminals

Copper Contacts

Rating : 60Amps @ 12Volts DC / 40Amps @ 24Volts DC

Mounting Stem : 5/8”(15.87mm) Diameter

With Rubber Cover and Mounting Nut



HEADLAMP DIMMER SWITCH

FE-A1401

Single Pole Double Throw Switch

2 Position On-On

3 Blade terminals

Bronze Contacts

Applications : Jeep 931201

FE-A1402

Single Pole Double Throw Switch

2 Position On-On

3 Blade terminals

Bronze Contacts

Single Pole Double Throw Switch

Same as FE-A1401

2 Position On-On

3 Blade terminals

Bronze Contacts

Applications : Jeep 931201

FE-A1404

Single Pole Double Throw Switch

2 Position On-On

3 Blade terminals

Bronze Contacts

Applications : Chrysler / Ford / Studebaker

FE-A1403

FE-A1405

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Mounting Stem : 3/4” and 1 3/4” on centers / 1/4”-20 Thread

Applications : Ford / Studebaker / Willys

FE-A1406

2 Position Off-(On)

2 Screw terminals

Iron Contacts

Mounting Stem : 3/4” and 1 3/4” on centers / 1/4”-20 Thread

Rating : 12Amps @ 12Volts DC

Waterproof and dustproof

FE-A1407

Same as FE-A1406 but with Wire Leads

2 Position Off-(On)

2 Terminals

R-type connectors

Mounting Stem : 3/4” and 1 3/4” on centers / 1/4”-20 Thread

Rating : 12Amps @ 12Volts DC

Waterproof and dustproof

headlamp dimmer switch/FE-A1401/SPDT/Jeep 931201
headlamp dimmer switch/FE-A1402/SPDT
headlamp dimmer switch/FE-A1403/SPDT/Chrysler/Ford/Studebaker
headlamp dimmer switch/FE-A1404/SPDT/Jeep 931201
headlamp dimmer switch/FE-A1405/SPDT/Ford/Studebaker/Willy
headlamp dimmer switch/FE-A146/waterproof/dustproof
headlamp dimmer switch/FE-A1407/R-type connectors/waterproof/dustproof
headlamp dimmer switch/drawing of FE-A1401
headlamp dimmer switch/drawing of FE-A1402
headlamp dimmer switch/drawing of FE-A1403
headlamp dimmer switch/drawing of FE-A1404
headlamp dimmer switch/drawing of FE-A1405
headlamp dimmer switch/drawing of FE-A1406
headlamp dimmer switch/drawing of FE-A1407

Dimemsions in m/m

FE-A1408

Single Pole Double Throw Switch

2 Position On-On

3 Blade terminals

Bronze Contacts

Rating : 8Amps @ 12Volts DC / 4Amps @ 24Volts DC

Applications : Merit 322200

FE-A1409-1

Single Pole Double Throw Switch

Same as FE-A1409 but with Iron Cap

2 Position On-On

3 Screw terminals

Bronze Contacts

Rating : 8Amps @ 12Volts DC / 4Amps @ 24Volts DC

Applications : Merit No. 322100

FE-A1410

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Universal and Heavy Duty type

FE-A1411

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Mounting Stem : 1 3/4” on centers

                        1/4”-20 Thread / 7/8” Diameter

Applications : Chrysler / Ford

FE-A1412

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Mounting Stem : 3/4” and 1 3/4” on centers

1/4”-20 Thread / 7/8” Diameter

Weather resistant seal in case

FE-A1413

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

Mounting Stem : 3/4” and 1 3/4” on centers

                        1/4”-20 Thread / 1 1/16” Diameter

FUSE BOX


headlamp dimmer switch/FE-A1410/SPDT/universal and haevy duty type
headlamp dimmer switch/FE-A1411/SPDT/Chrysler/Ford
headlamp dimer switch/FE-A1412/SPDT/weather resistant seal in case
hedlamp dimmer switch/FE-A1414/SPDT
headlamp dimmer switch/drawing of FE-A1408
headlamp dimmer swich/drawing of FE-A1409-1
headlamp dimmer switch/drawing of FE-A1410
headlamp dimmer switch/drawing of FE-A1411
headlamp dimmer switch/drawing of FE-A1412

FE-A1414

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Iron Contacts

headlamp dimmer switch/drawing FE-A1414
headlamp dimmer switch/drawing of FE-A1408-1

Single Pole Double Throw Switch

Same as FE-A1408 but with Iron Cap

2 Position On-On

3 Blade terminals

Bronze Contacts

Rating : 8Amps @ 12Volts DC / 4Amps @ 24Volts DC

Applications : Merit No. 322200

FE-A1408-1

headlamp dimmer switch/FE-A1408-1/SPDT/iro cap/Merit 322200
headlamp dimmer switch/drawing o FE-A1409
headlamp dimmer switch/FE-A1409/SPDT/Merit 322100

Single Pole Double Throw Switch

2 Position On-On

3 Screw terminals

Bronze Contacts

Rating : 8Amps @ 12Volts DC / 4Amps @ 24Volts DC

Applications : Merit No. 322100

FE-A1409

headlmp dimmer switch/drawing of FE-A1409-1/SPDT/iron cap/Merit 322100
headlamp dimmer switch/FE-A1408/SPDT/Merit 322200

Dimemsions in m/m

FE-A1502. A1522

6 Pole

Brass Contacts

With solid brass terminals and German type fuses

Rating : 8Amps

Applications : Mercedes Benz

FE-A1501. A1521

4 Pole

Brass Contacts

With solid brass terminals and German type fuses

Rating : 8Amps

Applications : Mercedes Benz

FE-A1503. A1523

8 Pole

Brass Contacts

With solid brass terminals and German type fuses

Rating : 8Amps

Applications : Mercedes Benz

fuse box/drawing of FE-A1501/drawing of F-A1521
fuse box/drawing of FE-A1502/drawing of FE-A1522
fuse box/drawing of FE-A1503/drawing of FE-A1523
fuse box/FE-A1501/4 pole/Mercedes Benz
fuse box/FE-A1521/4 pole/polycarbonate cover/Mercedes Benz
fuse box/FE-A1502/6 pole/Mercedes Benz
fuse box/FE-A1522/6 pole/polycarbonate cover/Mercedes Benz
fuse box/FE-A1503/8 pole/Mercedes Benz
fuse box/FE-A1523/8 pole/polycarbonate cover/Mercedes Benz

Polycarbonate Cover

Polycarbonate Cover

Polycarbonate Cover


FE-A1504

10 Pole

Brass Contacts

With solid brass terminals and German type fuses

Rating : 8Amps

Applications : Mercedes Benz

FE-A1505. A1525

12 Pole

Brass Contacts

With solid brass terminals and German type fuses

Rating : 8Amps

Applications : Mercedes Benz

fuse box/FE-A1504/10 pole/Mercedes Benz
fuse box/FE-A1505/12 pole/Mercedes Benz
fuse box/FE-A1525/12 pole/polycarbonate cover/Mercedes Benz
fuse box/drawing of FE-A1504
fuse box/drawing of FE-A1505/drawing of FE-A1525

Polycarbonate Cover

FE-A1510

In-Line Fuse Holder

Rating : 20 Amps @ 14 Gauge Wire

3AG Bakelite Fuse Holder

in-line fuse holder/FE-A1510/3AG bakelite fuse holder
in-line fuse holder/FE-A1510

Short W-R blade Fuse Holder

Applicable Fuse : ATC , ATO

Body Material : PVC

Wire length : 12" loop

Wires : 12# , 14# , 16# , 18#

Rated Current : 30Amps Max.

FE-A1511-1

short W-R blade fuse holder/drawing of FE-A1511-1
short W-R blade fuse holder/FE-A1511-1



FE-A1601

FE-A1602

FE-A1603

FE-A1605

FE-A1606

FE-A1607

FE-A1608

FE-A1609

FE-A1610

Through Panel Connector

For firewall or bulkhead

Positive(Red) and negative(Black)

through panel battery connector

through panel connector/FE-A1610/for firewall or bulkhead
remote charging terminal/FE-A1609/black jumper post/negative connection/insulated covers
remote charging terminal/drawing of FE-A1608
remote charging terminal/drawing of FE-A1609
through panel connector/drawing of FE-A1610

Suits Fuel Pressure Regulator Part No. FE-A1605

2 Size : 3/8” & 5/16”

Remote Charging Terminal

Jumper Post are Red in color

Used as the positive connection for charging the battery

Terminals have insulated covers

Remote Charging Terminal

Jumper Post are Black in color

Used as the negative connection for charging the battery

Terminals have insulated covers

2 Speed Heavy Duty Axle Switch

2 Position On-On

3 Snap-in terminals

Copper Contacts

Rating : 30Amps @ 12Volts DC

Die-Casting Body

Protected with rubber cover

Applications : Ford / IHC / Chrysler

Terminal Block Switch

2 Position On-On

4 Screw terminals

Copper Contacts

Mounting Stem : 8-32 Studs, 3/4” Long / 8-32 Studs, 7/32” Long

Applications : Ford / IHC / Chrysler / GMC

3 Terminals

R-type Connectors

Cable Accessory

Cord Only

Applications : Ford FAB 14668B

Fuel Pressure Regulator

With fittings and clamps

Chrome plated Zinc cast

Applications : Volkswagen 10-5622

Dashboard Lock

With 2 Keys

Key is only removable in the Off position

Fan Switch for Auto

Rating : 12Volts DC / 0.1~3.5Ω

2 speed heavy duty axle switch/die-casting body/rubber cover/Ford/IHC/Chrysler
terminals block switch/Ford/IHC/Chrysler/GMC
R-type connectors/FE-A1603/Ford FAB 14668B
fuel pressure regulator/FE-A1605/Volkswagen 10-5622
dashboard lock/FE-A1606
fan switch/FE-A1607/0.1~3.5Ω
2 speed heavy duty axle switch/drawing of FE-A1601
terminal block switch/dawing of FE-A1602
R-type connectors/drawing of FE-A1603
fuel pressure regulator/drawing of FE-A1605
dashboard lock/drawing of FE-A1606
fan switch/drawing of FE-A1607
remote charging terminal/FE-A1608/red jumper post/positive connection/insulated covers

TRUNK LOCK

Dimemsions in m/m

FE-A2601

Trunk Lock for Nissan

Applications : Nissan

trunk lock/FE-A2601/key set/Nissan
trunk lock/drawing of FE-A2601

FE-A2603

trunk lock/FE-A2603/Volkswagen

Trunk Lock for Volkswagen

Applications : Volkswagen

BATTERY ISOLATION SWITCH

FE-A3601

Single Pole Single Throw Switch

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 12Volts DC / Continuous Load 300Amps

                           / Intermittent Load 800Amps

Key is only removable in the Off position

battery isolation switch/FE-A3601/SPST/2 stud terminals
battery isolation switch/drawing of FE-A3601

Dimemsions in m/m

FE-A3601C

battery isolation switch/FE-A3601C/SPST/waterproof rubber cover/2 stud teminals

Single Pole Single Throw Switch

Same as FE-A3601 with Water-Proof Rubber Covers

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 12Volts DC / Continuous Load 300Amps

                           / Intermittent Load 800Amps

Key is only removable in the Off position

FE-A3602

Single Pole Single Throw Switch

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 12Volts DC / Continuous Load 300Amps

                           / Intermittent Load 800Amps

Key is only removable in the Off position

battery isolation switch/FE-A3602/SPST/2 stud terminals
battery isolation switch/drawing of FE-A3602

FE-A3603

Single Pole Single Throw Switch

Same as FE-A3602 with Water-Proof Rubber Covers

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 12Volts DC / Continuous Load 300Amps

                           / Intermittent Load 800Amps

Key is only removable in the Off position

battery isolation switch/FE-A3603/SPST/waterproof rubbe cover/2 stud terminals
battery isolation switch/drawing of FE-A3603

FE-A3604

Single Pole Single Throw Switch

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 12Volts DC / Continuous Load 300Amps

                           / Intermittent Load 800Amps

Red T Handle and is not removable

Zinc housing

battery isolation switch/FE-A3604/SPST/2 stud teminals
battery isolation switch/drawing of FE-A3604

Single Pole Single Throw Switch

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 12Volts DC / Continuous Load 300Amps

                           / Intermittent Load 800Amps

Red T Handle and is not removable

Zinc housing coated white paint

FE-A3604B

battery isolation switch/FE-A3604B/SPST/2 stud terminal
battery isolation switch/drawing of FE-A3604B

FE-A3605

Single Pole Single Throw Switch

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 12Volts DC / Continuous Load 300Amps

                           / Intermittent Load 800Amps

Red T Handle and is not removable

Zinc housing coated white paint

battery isolation switch/FE-A3605/SPST/2 stud terminal
battery isolation switch/drawing of FE-A3605

FE-A3605B

Single Pole Single Throw Switch

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 12Volts DC / Continuous Load 300Amps

                           / Intermittent Load 800Amps

Black T Handle and is not removable

Zinc housing coated white paint

battery isolation switch/FE-A3605B/SPST/2 stud terminal
battery isolation switch/drawing of FE-A3605B

FE-A3606

Single Pole Single Throw Switch

All heavy-duty industrial use

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 1-150Amps @ 24Volts DC

Iron T handle covered by red rubber and is not removable

Zinc housing

Universal Type

battery isolation switch/FE-A3606/SPST/heavy duty industrial use/universal type
battery isolation switch/drawing of FE-A3606

FE-A3607

Single Pole Single Throw Switch

2 Position Off-On , 2 Keys

2 Stud terminals

Copper Contacts

Rating : 12Volts DC / Momentary Load 450Amps

                           / Continual Load 250Amps

Indexing pins align switch and prevents rotation of housing

Key is only removable in the Off position

Replaces Caterpillar Part No. 7N0718

FE-A3606B

Single Pole Single Throw Switch

All heavy-duty industrial use

2 Position Off-On

2 Stud terminals

Copper Contacts

Rating : 1-150Amps @ 24Volts DC

Iron T handle covered by black rubber and is not removable

Zinc housing



FE-A3608

Master Disconnect Rotary Switch

2 Position Off-On

2 Stud terminals(3/8” Diameter)

Copper Contacts

Rating : 6-12Volts DC / Continual Load 250Amps

                              / Momentary Load 450Amps

Mounting Stem : 3/4”(19.05mm) Diameter / 11/16”(17.5mm) Long

Die Cast Case

Master Disconnect Rotary Switch

FE-A3608 but coated with waterproof glue at the bottom

2 Position Off-On

2 Stud terminals(3/8” Diameter)

Copper Contacts

Rating : 6-12Volts DC / Continual Load 250Amps

                              / Momentary Load 450Amps

Mounting Stem : 3/4”(19.05mm) Diameter / 11/16”(17.5mm) Long

Die Cast Case

FE-A3608A

FE-A3608B

Master Disconnect Rotary Switch

Same as FE-A3608 but coated with waterproof glue

2 Position Off-On

2 Stud terminals(3/8” Diameter)

Copper Contacts

Rating : 6-12Volts DC / Continual Load 250Amps

                              / Momentary Load 450Amps

Mounting Stem : 3/4”(19.05mm) Diameter / 11/16”(17.5mm) Long

Die Cast Case

FE-A3609

Master Disconnect Rotary Switch

2 Position Off-On

4 Stud terminals

Copper Contacts

Rating : 6-12Volts DC / Continual Load 250Amps

                     / Momentary Load 450Amps

Mounting Stem : 3/4”(19.05mm) Diameter / 11/16”(17.5mm) Long

Die Cast Case

FE-A3609B

FE-A3610

FE-A3611

FE-A3612

A3612Y01/2/3

Double Pole Single Throw Switch

2 Position Off-On

4 Stud terminals

Copper Contacts

Rating : 12Volts DC / Nominal Load 300Amps

                          / Instantaneous Load 1000Amps

Indexing pins align switch and prevents rotation of housing

Master Disconnect Rotary Switch

Same as FE-A3609 but coated with waterproof glue

2 Position Off-On

2 Stud terminals(3/8” Diameter)

Copper Contacts

Rating : 6-12Volts DC / Continual Load 250Amps

                              / Momentary Load 450Amps

Mounting Stem : 3/4”(19.05mm) Diameter / 11/16”(17.5mm) Long

Di
